Product: TMZ EW-106 Automatic Die Cutter
Overview
This listing is for a TMZ EW-106 automatic die cutting machine, manufactured in 2020 by TMZ. Key machine dimensions and capacities provided with the listing are included below. The listing indicates single ownership since new and that the machine is CE certified. The seller also notes that the manufacturer recommends a recommissioning service prior to returning the machine to production; an official quotation from TMZ is available.
Key specifications (as provided)
- Manufacturer: TMZ
- Model: EW-106
- Year of manufacture: 2020
- Maximum sheet size: as listed
- Minimum sheet size: as listed
- Maximum sheets/hour: as listed
- Machine dimensions (L × W × H): 4,600 mm × 2,300 mm × 2,080 mm
- Net weight: 17,000 kg
Features noted in the listing
- PLC electronic control and touch screen interface
- Automatic lubrication system
- Double action stripping unit and gripper waste removal system
- Complete standard accessories included
- CE certification
- Manufacturer-recommended recommissioning service available
Apparent equipment items and onsite condition to verify
The machine is fitted with a control panel with a rectangular display and several controls, a circular side port, multiple access panels, and a conveyor/roller system at the base. The housing is a grey metal enclosure labeled with manufacturer and model identification. Pallets and packaging materials are present around the base and shelving is nearby; a coiled hose/cable is located adjacent to the machine. Buyers should verify the presence and condition of these components and any accessories prior to purchase.
Notes for buyers
Confirm all technical details, accessories, hours of operation, and service history with the seller. If required, request additional photos, videos, and the manufacturer’s recommissioning quotation and documentation before proceeding.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
TMZ EW-106 Automatic Die Cutter
A rare opportunity to acquire a TMZ EW-106 Automatic Die Cutting Machine in exceptional condition.
Manufactured in 2020 and purchased new directly from TMZ Troqueladoras (Spain), this machine has had only one owner and has accumulated less than 300 operating hours since installation.
The machine has been used for a very limited production and has spent most of its life in storage.
Main Features
Manufacturer: TMZ Troqueladoras S.L.
Model: EW-106
Year of Manufacture: 2020
One Owner Since New
Less than 300 Operating Hours
CE Certified
PLC Electronic Control
Touch Screen Interface
Automatic Lubrication System
Double Action Stripping Unit
Gripper Waste Removal System
Complete Standard Accessories Included
Technical Specifications
Maximum Sheet Size: 760 × 1,060 mm
Minimum Sheet Size: 450 × 450 mm
Maximum Speed: 5,800 sheets/hour
Minimum Speed: 2,500 sheets/hour
Minimum Paper Weight: 200 g/m²
Maximum Corrugated Board Thickness: 6 mm
Maximum Cutting Pressure: 300 Tons
Maximum Pressure per dm²: 3.7 Tons
Minimum Gripper Margin: 9.5 mm
Main Motor: 9 kW
Machine Dimensions:
Length: 4,600 mm
Width: 2,300 mm
Height: 2,080 mm
Net Weight: 17,000 kg
Machine Condition
The machine has seen extremely limited use and remains mechanically in excellent condition.
Due to an extended storage period, TMZ has recommended a manufacturer recommissioning service before returning the machine to full production.
An official quotation from TMZ is available and can be supplied to interested buyers.
This recommissioning is intended to restore the machine to a condition very close to a new installation, providing complete confidence for long-term production.
Why This Machine?
Manufactured in 2020
Purchased new directly from TMZ
Single Owner
Less than 300 genuine working hours
Premium European Manufacturer
Immediate Availability
Complete Documentation
CE Certified
Excellent Investment Compared to the Cost of a New Machine (€287,955)
Location
Spain
Machine available for inspection by appointment.
Additional photographs, videos, serial number and official TMZ documentation are available upon request.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
