| Manufacturer | RUIAN XINCHENG ZHONGTAI |
|---|---|
| Model | ZTM-F 2500 |
| Year | 2022 |
| Location | Spain
|
This industrial slitting and rewinding machine, model ZTM-F 2500, is manufactured by RUIAN XINCHENG ZHONGTAI and was produced in 2022. It is designed primarily for processing various types of paper materials, including stick paper, craft paper, fluting paper, thermal paper, as well as plastic films. The machine accommodates jumbo roll widths ranging from 350 mm up to 2500 mm, with a working width of 2500 mm, allowing for versatile handling of large rolls.
The machine supports paper core diameters for the unwinder between 3 to 12 inches and can handle unwinder roll diameters up to 1850 mm. It is capable of managing jumbo roll weights up to 4500 kilograms. The paper thickness range it can process is between 40 to 440 gsm, suitable for a variety of paper grades. Rewinding diameters can also reach up to 1850 mm, with core diameters available in 76 mm, 152 mm, and 300 mm options.
Operational speeds vary from 10 to 600 meters per minute, providing flexible production rates. The slitting tolerance of the edge position control (EPC) system is within ±0.1 mm, ensuring precise cutting quality. The minimum slitting width achievable is 100 mm.
The machine weighs approximately 17,000 kg and requires a power supply of 380V, 3-phase, with a total power consumption of 80 kW. Its dimensions are 4700 mm in length, 5200 mm in width, and 4500 mm in height.
From the visible features, the machine has a robust white main frame equipped with multiple rollers essential for the slitting and rewinding process. A yellow safety guard or chute is positioned at the base of the machine, enhancing operator safety. Two vertical chrome poles extend above the main frame, possibly part of the unwinding or guiding system. There is also a control panel or electrical box mounted on the side for operational control and monitoring. The machine appears clean and well-maintained with no visible signs of damage, indicating it has been kept in good condition.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
The machine is mainly used to slit and rewind stick paper, craft paper, fluting paper, thermal paper, plastic film and other kinds of paper rolls, plastic
Jumbo roll width 350-2500mm
Dia. of paper core for unwinder 3-12’’
Diameter of Unwinder roll Ø1850mm
Max. Jumbo roll weight 4500kgs
Paper thickness range 40-440gsm
Diameter of rewinding Ø1850mm
Dia.of core for reiwnder 76mm, 152mm, 300mm
Slitting speed 10-600m/min
Tolerance of EPC ≤0.1mm
Min.slitting width 100mm
Weight 17000Kg
Power supply 380V-3Phases
Total power 80KW
Machine dimension 4700x5200x4500mm
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
Is this equipment testable?
This equipment is testable.
Does this equipment have CE marking?
This equipment has CE marking.
What size is the machine this equipment fits?
This equipment is for a smaller machine sized at 1600.
Why is the equipment being considered?
This equipment is being considered due to space and electrical power constraints.
What type of equipment is this?
This equipment is a High Speed Paper Slitter Rewinder.
The following questions and answers are generated using artificial intelligence based on the product information available. They are provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
| ruian-xincheng-zhongtai-ztm-f-2500-p241011161_4.pdf | Download |
| Client type | Factory – small or medium company |
| Active since | 2018 |
| Offers online | 1 |
| Last activity | Sept. 3, 2026 |
The machine is mainly used to slit and rewind stick paper, craft paper, fluting paper, thermal paper, plastic film and other kinds of paper rolls, plastic
Jumbo roll width 350-2500mm
Dia. of paper core for unwinder 3-12’’
Diameter of Unwinder roll Ø1850mm
Max. Jumbo roll weight 4500kgs
Paper thickness range 40-440gsm
Diameter of rewinding Ø1850mm
Dia.of core for reiwnder 76mm, 152mm, 300mm
Slitting speed 10-600m/min
Tolerance of EPC ≤0.1mm
Min.slitting width 100mm
Weight 17000Kg
Power supply 380V-3Phases
Total power 80KW
Machine dimension 4700x5200x4500mm
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
Is this equipment testable?
This equipment is testable.
Does this equipment have CE marking?
This equipment has CE marking.
What size is the machine this equipment fits?
This equipment is for a smaller machine sized at 1600.
Why is the equipment being considered?
This equipment is being considered due to space and electrical power constraints.
What type of equipment is this?
This equipment is a High Speed Paper Slitter Rewinder.
The following questions and answers are generated using artificial intelligence based on the product information available. They are provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
