| Manufacturer | Duetti |
|---|---|
| Model | Fin de ligne |
| Year | 2018 |
| Location | France
|
For sale: a used DUETTI Packaging end-of-line case packing system (2018) composed of an automatic carton former (FORMER 20H), a bottle case packer/loader (PACKER 10) and a carton sealer (CHMSS). The line is configured for packing bottles into American-style cartons and was manufactured by Duetti Packaging (Galliera Veneta, Italy). It was installed and commissioned in late 2018 and remains installed and in production; it can be viewed in operation and inspected upon request. Available starting February 2027.
Configured formats and throughput
- Carton formats: 12 x 33 cl and 6 x 75 cl
- Throughput: up to approximately 10 cartons per minute
- Approximate capacities: 6,000 bottles/hour for the 33 cl format and 3,000 bottles/hour for the 75 cl format
Main machine summaries
DUETTI FORMER 20H (automatic carton former)
- Automatic flat carton feeder and vacuum gripper system
- Automatic opening and forming of blanks, folding of bottom flaps and bottom sealing
- Hot-melt application via 4 nozzles and a pressure system to ensure bonding
- Automatic transfer with 90° output to the case packer
DUETTI PACKER 10 (automatic bottle case packer)
- Bottle conveying and distribution across four lanes
- Automatic batch formation and bottle detection via sensors
- Automatic gripping head with inflatable grippers and Cartesian motion for vertical insertion of bottles into cartons
DUETTI CHMSS (carton sealer)
- Automatic top-flap folding and hot-glue application with four gluing nozzles
- Pressure rollers to secure the glue bond and conveyors for carton transfer
Line conveyors and transfer details
- Cartons are transported through the former and sealer using high-grip side belts (no pusher pin system)
- Separate conveyor for the case loading area
- An inclined transfer belt currently connects the case loader to the sealer; this section can be adjusted to a horizontal position by adjusting the sealer height
Documentation and exclusions
- Supplied with user manuals, technical documentation, electrical diagrams and CE declarations of conformity
- Systems for printing, marking or coding cartons are not included in the sale
Condition
- Used packaging line currently in production and still installed and powered at its site. Viewing and inspection in operation are available by appointment.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
For sale: a used DUETTI Packaging packaging line from 2018, consisting of an automatic carton former, a bottle case loader, and a carton sealer.
This complete end-of-line system is designed for the automatic packaging of bottles in American-style cartons.
Manufactured by Duetti Packaging in Galliera Veneta, Italy, the line was installed and commissioned in late 2018.
It is currently still in production at a brewery in France and can be viewed and tested in operation upon request.
The line is currently configured for the following formats:
Cartons of 12 bottles, 33 cl each
Cartons of 6 bottles, 75 cl each
Production Rate
Approximately 6,000 bottles per hour for the 33 cl format
Approximately 3,000 bottles per hour for the 75 cl format
Current maximum rate: approximately 10 cartons per minute
This line is suitable for breweries, beverage producers, wineries, wine estates, cideries, and other bottling industries seeking an automated case-packing solution.
Technical Specifications
Manufacturer: Duetti Packaging
Models: FORMER 20H + PACKER 10 + CHMSS
Year of manufacture: 2018
Commissioned: late 2018
Type: automatic case packing line
Function: forming, loading, and sealing cases
Carton type: American-style cartons
Current formats: 12 x 33 cl and 6 x 75 cl
Throughput: up to approximately 10 cartons/minute
Capacity: approximately 6,000 bottles/hour for 33 cl
Capacity: approximately 3,000 bottles/hour for 75 cl
Carton Sealing: hot-melt adhesive
Adhesive Dispenser: Meler Micron 5
DUETTI FORMER 20H Automatic Carton Former
The DUETTI FORMER 20H carton former automatically picks up flat carton blanks, opens them, forms them into boxes, and seals the bottom.
Main features:
Automatic flat carton feeder
Vacuum gripper / vacuum system
Automatic opening and forming of cartons
Automatic folding of bottom flaps
Application of hot-melt adhesive via 4 nozzles
Pressure system to ensure bonding
Automatic transfer of cartons
90° output to the case packer
DUETTI PACKER 10 automatic bottle case packer
The DUETTI PACKER 10 case packer automatically groups bottles and places them into cartons.
It includes, in particular:
Bottle conveying
Distribution across 4 lanes
Automatic batch formation
Bottle detection via sensors
Automatic gripping head
Inflatable grippers for handling bottles
Cartesian motion
Automatic vertical insertion of bottles into cartons
This automatic bottle case packer automates the case-packing process while minimizing manual handling.
DUETTI CHMSS Carton Sealer
After case packing, the cartons are transferred to the DUETTI CHMSS automatic carton sealer.
he machine performs the following functions:
Automatic folding of the top flaps
Application of hot glue
4 gluing nozzles
Automatic carton sealing
Pressure rollers to ensure the glue bond holds
Conveyors and carton transfer
The line features various conveyors that automatically transfer cartons between the forming machine, the case packer, and the sealer.
Cartons are transported through the forming machine and the sealer via high-grip side belts, without a pusher pin system.
The case loading area also has its own conveyor.
An inclined transfer belt currently connects the case loader to the case sealer. This section can be adjusted to a horizontal position by adjusting the height of the case sealer.
DUETTI Line Documentation
The line is sold with the following technical documentation available:
User manuals
Technical documentation
Electrical diagrams
CE declarations of conformity
The system for printing, marking, or coding cartons is not included in the sale.
Condition of the Packaging Line
Used packaging line currently in production.
The DUETTI line is still installed, powered, and in use at its current location.
It can be viewed in operation in France by appointment, allowing you to verify its condition and functionality before purchase.
Available starting in February 2027.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
