| Manufacturer | TECNOVA SRL |
|---|---|
| Model | ES 130/37D DEG |
| Year | 2005 |
| Location | Netherlands
|
Manufacturer: TECNOVA SRL (Tecnova S.r.l., Italy)
Model: ES 130/37D DEG
Year of manufacture: 2005
Overview:
Complete plastic recycling and regranulation production line for thermoplastics. The line combines single-screw extrusion with vacuum degassing, hydraulic melt filtration, die-face hot-cut pelletizing, water cooling and centrifugal pellet drying to deliver regranulated material in a continuous process.
Key technical features (as provided):
- Extruder type: Single-screw recycling extruder
- Screw diameter: 130 mm
- L/D ratio: 37:1
- Degassing: Vacuum degassing system (DEG)
- Temperature control: Six individually controlled barrel zones
- Barrel heating: Electrical heating
- Barrel cooling: Forced-air cooling with individual cooling fans
- Total heating capacity: Approximately 110.6 kW
- Melt filtration: Hydraulic screen changer
- Melt pressure monitoring: Included
- Pelletizing system: Hot-cut / die-face pelletizing
- Pellet cooling: Water-cooled
- Pellet drying: Centrifugal drying system
- Drive: Main extruder motor with industrial gearbox
- Control system: Industrial control system for monitoring extrusion parameters, temperature regulation and melt pressure monitoring
Line configuration and scope:
The supplied configuration includes the main extruder with degassing/vacuum equipment, hydraulic melt filtration, die-face cutting (hot-cut) pelletizing system, water cooling and centrifugal pellet-drying equipment. The line is described as a used industrial recycling installation.
Documentation and inspection:
Technical documentation and manuals are available. Inspection and further technical information are available upon request.
Condition note:
Listed as a used installation. No additional operational or testing status is claimed in the provided information.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Manufacturer: Tecnova S.r.l., Italy
Model: ES130/37D DEG
Year of manufacture: 2005
Overview: Plastic recycling and regranulation line for thermoplastics, combining extrusion, degassing, melt filtration, pelletizing, cooling and drying in one complete production process
Extruder type: Single-screw recycling extruder
Screw diameter: 130 mm
L/D ratio: 37:1
Degassing: Vacuum degassing system (DEG)
Temperature control: 6 individually controlled barrel zones
Barrel heating: Electrical heating
Barrel cooling: Forced-air cooling with individual cooling fans
Total heating capacity: Approximately 110.6 kW
Melt filtration: Hydraulic screen changer
Melt pressure monitoring: Yes
Pelletizing system: Hot-cut / die-face pelletizing system
Pellet cooling: Water-cooled
Pellet drying: Centrifugal drying system
Drive: Main extruder motor with industrial gearbox
Applications: Plastic recycling and regranulation
Process stages: Extrusion, degassing, melt filtration, pelletizing, cooling and drying
Line configuration: Main extruder with degassing/vacuum equipment, hydraulic melt filtration, die-face cutting system, water cooling and centrifugal pellet drying equipment
Control system: Industrial control system for monitoring extrusion, temperature regulation and melt pressure monitoring
Condition: Used industrial recycling installation
Origin: Italy
Documentation: Technical documentation/manuals available
Inspection/technical information: Available upon request
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Factory – small or medium company |
| Active since | 2026 |
| Offers online | 1 |
| Last activity | Sept. 7, 2026 |
Manufacturer: Tecnova S.r.l., Italy
Model: ES130/37D DEG
Year of manufacture: 2005
Overview: Plastic recycling and regranulation line for thermoplastics, combining extrusion, degassing, melt filtration, pelletizing, cooling and drying in one complete production process
Extruder type: Single-screw recycling extruder
Screw diameter: 130 mm
L/D ratio: 37:1
Degassing: Vacuum degassing system (DEG)
Temperature control: 6 individually controlled barrel zones
Barrel heating: Electrical heating
Barrel cooling: Forced-air cooling with individual cooling fans
Total heating capacity: Approximately 110.6 kW
Melt filtration: Hydraulic screen changer
Melt pressure monitoring: Yes
Pelletizing system: Hot-cut / die-face pelletizing system
Pellet cooling: Water-cooled
Pellet drying: Centrifugal drying system
Drive: Main extruder motor with industrial gearbox
Applications: Plastic recycling and regranulation
Process stages: Extrusion, degassing, melt filtration, pelletizing, cooling and drying
Line configuration: Main extruder with degassing/vacuum equipment, hydraulic melt filtration, die-face cutting system, water cooling and centrifugal pellet drying equipment
Control system: Industrial control system for monitoring extrusion, temperature regulation and melt pressure monitoring
Condition: Used industrial recycling installation
Origin: Italy
Documentation: Technical documentation/manuals available
Inspection/technical information: Available upon request
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
Manufacturer: TECNOVA SRL (Tecnova S.r.l., Italy)
Model: ES 130/37D DEG
Year of manufacture: 2005
Overview:
Complete plastic recycling and regranulation production line for thermoplastics. The line combines single-screw extrusion with vacuum degassing, hydraulic melt filtration, die-face hot-cut pelletizing, water cooling and centrifugal pellet drying to deliver regranulated material in a continuous process.
Key technical features (as provided):
- Extruder type: Single-screw recycling extruder
- Screw diameter: 130 mm
- L/D ratio: 37:1
- Degassing: Vacuum degassing system (DEG)
- Temperature control: Six individually controlled barrel zones
- Barrel heating: Electrical heating
- Barrel cooling: Forced-air cooling with individual cooling fans
- Total heating capacity: Approximately 110.6 kW
- Melt filtration: Hydraulic screen changer
- Melt pressure monitoring: Included
- Pelletizing system: Hot-cut / die-face pelletizing
- Pellet cooling: Water-cooled
- Pellet drying: Centrifugal drying system
- Drive: Main extruder motor with industrial gearbox
- Control system: Industrial control system for monitoring extrusion parameters, temperature regulation and melt pressure monitoring
Line configuration and scope:
The supplied configuration includes the main extruder with degassing/vacuum equipment, hydraulic melt filtration, die-face cutting (hot-cut) pelletizing system, water cooling and centrifugal pellet-drying equipment. The line is described as a used industrial recycling installation.
Documentation and inspection:
Technical documentation and manuals are available. Inspection and further technical information are available upon request.
Condition note:
Listed as a used installation. No additional operational or testing status is claimed in the provided information.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
